The L1311A knee joint is a light single axis knee joint that offers a weight activated brake function with manual lock feature: its 2-in-1 function means it can be used as part of the rehabilitation phase. As a locked knee joint, it is particularly suitable for initial standing and gait exercise. With increased mobility, the knee can be set to a nonlocking weight activated brake function. The brake feature guarantees a controlled flexion and extension profile.

Indications

  • Ideal for the rehabilitation phase
  • Manual locking feature provides a high degree of safety when required
  • Ability to switch between a locked and weight activated brake knee joint
  • Adaptable to the patient’s progress

Product benefits

  • Single Axis knee
  • Locking function for a high degree of safety for initial standing and gait exercises.
  • Flexion and extension can be released depending on the patients progress
  • Flexion and extension swing adjustment
  • Extension assist spring
  • Individually selectable level of safety in definitive therapy
  • Clinician adjustable features: Rates of flexion and extension can be adapted to the user’s wishes

Specs

Weight limit: 125kg/275lbs
Build height: 65mm
Knee centre to mid ball: 26mm
Knee flexion: 145 Degrees
Product weight: 495g
Material: Aluminum
Warranty: 2 year
